Cambium Networks

Wireless That Just Works

Cambium accessories provide the simplest way to build your wireless network, delivering the peace of mind and value of Cambium-engineered and -approved products.

Our wireless network components are designed to optimize reliability and performance while minimizing total cost of ownership. These accessories enable network operators to tailor the wireless broadband network capacity and range to meet the exact needs of business and residential end customers. Accessories optimize the Point-to-Point wireless backhaul and Point-to-Multipoint wireless distribution and access networks to offer the services that customers demand.

Sub-6 GHz Accessories Guide PTP 820/850 Accessories Guide
CAM Accessories

Power Supplies

Product Volts Wattage With AUX Power AC input PoE Injector AC+DC Power Supply DC input PoE AC input Power Supply
PTP 550 56V 30W X N000000L034B X X X
PTP 550E 56V 30W X N000000L034B X X X
PTP 670 56V 35W 70W N000065L001C C000065L002D X X
PTP 48700 56V 40W 70W X C000065L002D X X
PTP 78700 56V 70W 100W X C000065L002D X X
60GHz cnWave V1000 56V 10W X N000900L017A X X X
60GHz cnWave V3000 56V 30W 60W N000000L142A,C000000L141A,N000065L001C N000000L179B X X
60GHz cnWave V5000 56V 35W 65W N000000L142A,C000000L141A,N000065L001C N000000L179B X X
PMP 450 30V 15W X N000900L001D X X X
PTP 450i 56V 30W 60W N000000L034B,N000065L001C C000065L002D N000000L036A X
PTP 450b 30V 15W X N000900L001D X X X
5Ghz PMP 450m 56V 80W 110W X C000065L002D X X
3Ghz PMP 450m 56V 150W 180W X N000000L054B X X
ePMP 3000 56V 30W X N000000L034B X X X
ePMP 3000L 30V 15W X N000900L001D X X X
ePMP 3000 MP 56V 15W X N000900L017A X X X
ePMP Force 180 30V 15W X N000900L001D X X X
ePMP Force 190 30V 15W X N000900L001D X X X
ePMP Force 200 30V 15W X N000900L001D X X X
ePMP Force 200L 30V 15W X N000900L001D X X X
ePMP Force 300-13 30V 15W X N000900L001D X X X
ePMP Force 300-13L 30V 15W X N000900L001D X X X
ePMP Force 300-16 30V 15W X N000900L001D X X X
ePMP Force 300-19 30V 15W X N000900L001D X X X
ePMP Force 300-19R 30V 15W X N000900L001D X X X
ePMP Force 300-25 30V 15W X N000900L001D X X X
ePMP Force 300-25L 30V 15W X N000900L001D X X X
ePMP Force 300 30V 15W X N000900L001D X X X
ePMP Force 425 56V 30W X N000000L034B X X X
ePMP Force 400C 56V 30W X N000000L034B X X X
2GHz cnRanger 101 SM 30V 7.5W X N000900L001D X X X
2GHz cnRanger 201 SM 30V 9W X N000900L001D X X X
3GHz cnRanger 201 SM 30V 9W X N000900L001D X X X
3GHz cnRanger RRH 48V 60W X X X X N000000L129A
2GHz cnRanger RRH 48V 72W X X X X N000000L129A

SFPs

Product SFP 1G 850nm 1G 1310nm 1G Copper 1G SFP 1490nmTx
/1310nm Rx		 1G SFP 1310nmTx
/14900nm Rx		 1G CSFP 1490nmTx
/1310nm Rx		 1G SFP C1310nmTx
/14900nm Rx		 10G 850nm 10G 1310nm 10G Copper 40G
PTP 550 X C050055L002A C050055L003A C050055L001A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 550E X C050055L002A C050055L003A C050055L001A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 670 X C000065L009A C000065L008A C000065L010A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 700 4400-5725 MHz X C000065L009A C000065L008A C000065L010A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 700 7125-8500 MHz X N000070L016A N000070L015A N000070L017A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 820E X N000082L072A N000082L059A N000082L117A N000082L213A N000082L214A N800082L011A N800082L010A N800082L012A N800082L013A N/A N/A
PTP 820F X N000082L072A N000082L059A N000082L117A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 820G X N000082L072A N000082L059A N000082L117A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 820S X N000082L072A N000082L059A N000082L117A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 820C HP X N000082L072A N000082L059A N000082L117A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 820C X N000082L072A N000082L059A N000082L117A N/A N/A N/A N/A N/A N/A N/A N/A
PTP 850E X N000082L072A N000082L059A N000082L117A N000082L213A N000082L214A N800082L011A N800082L010A N800082L012A N800082L013A N/A N000082L203A
PTP 850C X N000082L072A N000082L059A N000082L117A N000082L213A N000082L214A N800082L011A N800082L010A N800082L012A N800082L013A N/A N/A
PTP 850S X N000082L072A N000082L059A N000082L117A N000082L213A N000082L214A N800082L011A N800082L010A N800082L012A N800082L013A N/A N000082L203A
V3000 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
V5000 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
PMP 450m X C000065L009A C000065L008A C000065L010A N/A N/A N/A N/A N/A N/A N/A N/A
EX1010 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX1010-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX1028 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX1028-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX2010 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX2010-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A N/A N/A N/A N/A
EX2028 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
EX2028-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
EX2016M-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
EX2052 X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
EX2052-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
EX2052R-P X SFP-1G-SX SFP-1G-LX SFP-1G-Copper N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A
cnRanger RRH 2 and 3 GHz X SFP-1G-SX N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
cnRanger Sierra 800 BBU X SFP-1G-SX N/A N/A N/A N/A N/A N/A SFP-10G-SR SFP-10G-LR SFP-10G-Copper N/A

Featured Accessories

cnPulse Sync Generator

cnPulse is the latest GPS synchronization generation device designed specifically for Cambium Networks PMP and PTP radios. The cnPulse module is IP67 (weather proof and supports a wide temperature range for rugged environments.The GPS receiver is highly reliable and supports both GPS and GNSS signals. cnPulse gets it power from…

30v Gigabit Surge Supressor

Cambium Networks designs outdoor wireless broadband solutions to operate in the toughest of environments. Lightning strikes are the most typical cause of system outages or failures of mast-mounted equipment especially when mounted as high as 300m. The 30v Gigabit Surge Suppressor is critical for lightning protection to minimize the potential…

outdoor

4.9 to 5 GHz Dual Pole 90 Degree Sector Antenna

Sector antenna solution for PTP 670/700 High Capacity MultiPoint (HCMP) radios that enables network operators to connect up to eight PTP radios to a single HCMP access point. Especially well-suited to high-density networks requiring frequency re-use and wide-band spectrum coverage, as well as video surveillance and mission critical infrastructure backhaul…

outdoor

Quick Deploy Positioner

With the Quick Deploy (QD) Positioner, networks can be initially set up and then periodically moved to new locations safely and quickly — ensuring optimal alignment and link reliability

Reflector Dish

The Reflector Dish provides additional system gain, enhancing range and improving performance in nLOS and NLOS environments.

PTP Sync Unit

Designed for PTP 650 Series, the PTP Sync Unit module synchronizes multiple PTP 650 connections by providing a common clock signal and GPS signal reference.

Lightning Protection Unit

Lightning strikes are the most typical cause of system outages or failures of mast-mounted equipment, especially when mounted as high as 300m. The Cambium Networks Lightning Protection Unit designed for the PTP 650 Series are ruggedized to operate in the toughest environments.

Network Indoor Unit

Network Indoor Unit

The PTP 650 Network Indoor Unit (NIDU) is a hardware device which enables the passing of T1/E1 TDM circuits over PTP 650 fixed wireless broadband connections. Using the NIDU, information from existing TDM circuits is delivered reliably, meeting the precise latency and jitter requirements needed for T1/E1 traffic.
